Governor

Governor

Disassembly

1. Remove the governor body attaching bolts and remove the governor.






2. Remove the snap ring that secures the governor oil collector body on the output shaft (Fig. 29) and slide it off the front of the shaft.
3. Remove the seal rings from the oil collector body.

Assembly

1. Carefully install new seal rings on the oil collector body.
2. Working from the front end of the output shaft, slide the governor oil collector body into place on the shaft. Install the snap ring to secure it. Make sure that the snap ring is seated in the groove.






3, Position the governor assembly on the oil collector body (Fig. 29) and secure with the attaching screws. Tighten screws to 10.5-13.5 N.m (90-120 in-lbs).
